Climate Pro D12

Year-round utility with heating and cooling from a single unit.

The Climate Pro D12 heat pump is an all-in-one system for temperature control in any season. It delivers 11,450 Btu/h of cooling and 9,900 Btu/h of heating — with a space-saving footprint of just over 4 sq. ft.

  • Minimal electricity. Runs on 115V with 15 amp circuit and consumes just 1.38 kW (cooling) or 1.25 kW (heating).

  • Effective cooling in conditions from 65° to 95°F.

  • Provides heating in conditions from 24° to 80°F (with plenum and air entering outdoor heat exchanger).

11,450 Btu/h

Cooling Capacity

9,900 Btu/h

Heating Capacity

1 Phase, 115V

Voltage

Find your local MovinCool dealer

Climate Pro D12 Features

The value you expect.

Avoid downtime from overheated electronics and lost productivity from employee discomfort.

The Climate Pro D12 brings advanced design to give you the best in safety and ease of operation.

See all the features that distinguish the entire Climate Pro Series.

    Advanced features include:

    • Programmable electronics for automatic operation after hours and on weekends.
    • Wireless connectivity-ready for remote monitoring and e-notifications of performance.
    • Quick-connect nozzle for simple, time-saving setup.
    y

    Quiet, reliable operation.

    Quiet operation. At highest speed with condenser duct, sound level 61 dB(A) — about as much sound as an electric toothbrush.

    Downloads


    Category


    Title


    Language


    File

    Installation Manuals Climate Pro D12 D18 K12 K18 K24 X14 X20 X26 Installation Manual Condensate Pump Kit English Download File
    Installation Manuals Climate Pro D12 D18 K12 K18 K24 X14 X20 X26 Installation Manual Nozzles English Download File
    Installation Manuals Climate Pro D12 D18 K12 K18 K24 X14 X20 X26 Installation Manual Plenum English Download File
    Operation Manuals Manual de Operación (Climate Pro® D12, D18) Spanish MovinCool Operation Manual CPD12_18 (0120 to present)_484007-4770ES.pdf
    Operation Manuals Mode d'emploi (Climate Pro® D12, D18) French MovinCool Operation Manual CPD12_18 (0120 to present)_484007-4770FR.pdf
    Operation Manuals Operation Manual (Climate Pro® D12, D18) English MovinCool Operation Manual CPD12_18 (0120 to present)_484007-4770EN.pdf
    Product Literature Climate Pro D Series Product Sheet English Download File
    Product Literature MovinCool Catalog 2020 English Download File
    Spare Parts Catalogs Climate Pro D12 Spare Parts Catalog 1st edition MovinCool Spare Parts Catalog CPD12_1st edition.pdf

    Specifications


    Electronic Features

    Control PanelProgrammable

    Cooling Capacity

    Rating Conditions:
    Cooling: Indoor @ 80°F / Outdoor @ 80°F @ 50% RH
    Cooling: 11,450 Btu/h
    Heating: Indoor @ 70°F / Outdoor @ 47°F @ 50% RHHeating: 9,900 Btu/h

    Electrical Characteristics

    Voltage Requirement1 Phase, 115 V, 60 Hz
    Total Power ConsumptionCooling: 1.38 kW, Heating: 1.25 kW
    Current ConsumptionCooling: 12.1 amps, Heating: 13.3 amps
    Recommended Fuse Size15 amps
    NEMA Plug Configuration5-15P
    Min. - Max. Voltage104 - 127 V

    Fans

    Air Volume - High/Mid/Low420/340/280 CFM
    Outdoor Fan760 CFM

    Indoor Heat Exchanger (Supply)

    Fan TypeCentrifugal
    Max. Air Flow - High/Mid/Low420/340/280 CFM
    Max. External Static Pressure0.31 IWG

    Outdoor Heat Exchanger (Exhaust)

    Fan TypeCentrifugal
    Max. Air Flow760 CFM
    Max. External Static Pressure0.19 IWG

    Compressor

    TypeHermetic Rotary
    Output 0.75 kW

    Refrigerant

    Type R-410A

    Dimensions

    W x D x H22 x 27 x 47 in

    Weight

    Net / Shipping181 / 218 lb

    Power Cord

    Gauge14 AWG (3-core)
    Length10 ft

    Condensate Tank

    Capacity5 gal

    Operating Conditions

    Min. - Max. @ 50% RHCooling: 65° - 95°F
    Heating:
    Without Plenum: 40°F - 80°F (Air entering indoor and outdoor heat exchangers)
    With Plenum: 40°F - 80°F (Air entering indoor heat exchanger) 24°F - 80°F (Air entering outdoor heat exchanger)

    Max. Duct Length

    Supply Duct Hose30 ft
    Exhaust Duct Hose100 ft

    Max. Sound Level

    With Condenser Duct - High/Mid/Low61/60/59 dB(A)
    Without Condenser Duct - High/Mid/Low62/61/60 dB(A)

    Specifications subject to change without notice. All models feature compressor overload relay and fan motor protection. All models also feature compressor short-cycle protection, return air thermostat, automatic restart and accommodate a condensate pump kit. All portable models are 50 Hz-compatible with a slight performance decrease from specifications listed.


    Accessories


    #


    Part Num


    Item


    Description

    1481170-0450Supply Air Flange Kit, 5-in dia. 5-in diameter white metal flange with wire clamp and mounting screws. Use with supply air ducts.
    2484209-0480Nozzle Kit, 5-in dia.5-in diameter plastic nozzle that extends up to 2 feet in length. Quick connect type. Includes trim ring.
    4481744-0091Self-Supported Duct, 5-in dia.5-in diameter, white plastic duct that extends from 6.5 to 10 feet in length.
    5481851-0200Trim Ring, 5-in dia.5-in diameter black plastic ring mounts as end caps for extension duct.
    6481170-0480Supply Air Flange Kit, 5-in dia., Quick Connect type5-in diameter white metal flange with wire clamp and mounting screws. Quick Connect Type. Use with supply air ducts.
    6A481769-0280Nozzle Adapter Kit, 5-in dia.Adapter converts airflow from louvers to nozzles or air ducts.
    8LAY45771-0060Flexible Air Duct, 12-in dia. (not shown)12-in diameter wire-reinforced, accordion-style duct in 10-ft length for outdoor air exhaust. Includes clamp.
    9LA146373-8280Celling Tile Kit, 12-in hole, plastic24-in x 24-in plastic white tile with 12-in hole for exhaust air self-supported duct.
    9484490-1030Celling Tile Kit, 12-in hole, metal24-in x 24-in sheet metal tile with 12-in hole and built-in flange for exhaust air flexible duct kit
    10484350-1340Outdoor Air PlenumPlenum for return air to the outdoor heat exchanger.
    11484789-0210Condensate Pump Kit, 110V115V pump kit includes 3/8-in diameter x 20-ft length hose. Includes installation hardware. Maximum lift: 20 feet at 115V
